Futuro Portofino 32 in. 940 CFM Champagne Downdraft Induction Cooktop | HB32PORTOFINO-CHM

Streamline your modern kitchen with the Futuro Futuro Portofino 32-Inch Downdraft Hub. This cutting-edge appliance seamlessly combines a high-performance induction cooktop with a powerful, integrated 940 CFM downdraft range hood. By eliminating the need for an overhead vent, the Portofino offers a sleek, unobstructed view while delivering exceptional air purification right at the cooking surface. With flexible flush or standard installation options, this all-in-one workstation perfectly balances minimalist aesthetics with smart, professional-grade culinary technology.



Cooktop Features:

• Permanent Pot Detection: The cooking surface activates only when cookware is placed on the designated zones, ensuring precision and energy efficiency. If the cookware is removed or absent, heating automatically halts.

• Safety Shutdown: Each cooking zone features a built-in safety timer that limits operation based on the power setting, shutting off automatically for enhanced safety.

• Residual Heat Indicator: To keep users safe, the cooktop displays a clear “H” symbol on any zones that remain hot after use, serving as a visual warning.

• Booster Function (Level "P"): For rapid heating, the Booster mode provides extra power for up to 5 minutes before reducing to level 9. Ideal for boiling water or cooking large quantities quickly.

• Key Lock Function: Lock the cooktop settings to prevent accidental changes during operation, ensuring a smooth cooking process.


• Child Lock Function: Designed with safety in mind, the Child Lock feature prevents unauthorized or accidental operation by locking power adjustments, cooking zones, and timers.


• Chef Cook Function: Simplify complex cooking tasks with the Chef Cook feature, which lets you set different power levels across different zones with a single press.


• Automatic Heat-Up Function: Rapidly bring pots to cooking temperature using full power, then seamlessly transition to your desired heat level to prevent overcooking.


• Warming Function: Maintain cooked food at an ideal temperature with the Warming function, ensuring dishes stay ready to serve.


• Autonomous Timer Function: An independent timer operates separately from the cooking zones and emits an audible alert when the countdown is complete—ideal for multitasking.


• Bridge Function: Combines two adjacent zones into a single, unified cooking area for even heating, making it ideal for oversized pots and specialty cookware.




Ventilation Features:

• Intelligent Downdraft Ventilation: The integrated downdraft range hood automatically adjusts its suction power based on the intensity of your cooking. As heat levels rise or fall, the ventilation system dynamically adjusts airflow to eliminate odors, smoke, and steam effectively.

• Adjustable Timer with Delayed Shut-Off: Control your kitchen’s air quality with a delayed shut-off feature that allows the range hood to continue operating for a preset duration after cooking. This ensures that all residual cooking fumes are thoroughly removed, leaving your space fresh and clean.


• Maintenance Reminders for Filters: The Portofino Hub alerts you when the grease filters need cleaning, simplifying maintenance and ensuring the hood operates at peak efficiency. Regular cleaning of the metal grease filter prevents buildup and extends the lifespan of the ventilation system.

• Elegant Glass Flap Design: The stylish glass flap not only enhances the cooktop’s appearance but also improves functionality. When opened, it activates immediate suction for cooking fumes. Closing the flap deactivates the ventilation, and a built-in sensor ensures the process is seamless. For added convenience, the glass flap can be removed for cleaning.

• Dishwasher-Friendly Filters and Drip Tray: Both the grease filter and the drip tray are designed for effortless cleaning. Simply remove them after opening the glass flap and place them in the dishwasher for hassle-free maintenance.

• Waterproof Motor with Drainage System: Equipped with a water-resistant motor, the Portofino Hub ensures long-lasting performance, even in the presence of accidental liquid contact. The built-in drain valve protects the motor and provides easy water removal for added durability.

• Compact Motor Positioning: The space-saving motor placement beneath the glass flap simplifies installation and maximizes storage below the cooktop, giving you more room for kitchen essentials.

• Versatile Installation Options: Choose between flush (filotop) or standard installation to match your kitchen design. This flexibility allows you to create a streamlined, modern aesthetic while maintaining the hub’s high performance.


*CFM can be reduced upon customer request to accommodate local building code requirements. Simply contact us after placing your order.

Specifications

Brand	Futuro Futuro
Origin Country	Italy
Control Type:	Futuristic touch-sensitive optical control panel
Filter Type	Downdraft
Dimensions	Width: 32 in. Depth: 20.5 in. Height: 10 in.
Electrical Requirements:	Direct Wire Connection, 220-240 Volts, 60 Hz, 32 Amp
Exhaust Type	Ducted or Ductless (Convertible)
Noise Level	0.5 - 3.2 Sones
Finish:	Ceramic Glass
Certifications:	UL, CSA Listed for USA and Canada
Speed Levels	9 + Booster Function
Duct Size:	N/A - Ductless
Motor Size:	940 CFM
Warranty:	1-year service repair + 2-year parts warranty



Manuals

Installation Manual



Portofino Presentation





Manufacturer Warranty

Warranty Coverage
Futuro Futuro guarantees that all products will be free from material and workmanship defects for three (3) years from the original purchase date when used under normal household conditions in the Contiguous United States. This warranty applies exclusively to the original purchaser.



Eligibility

• Valid only for products purchased directly from authorized Futuro Futuro retailers.
• Applies to ordinary home use within the Contiguous U.S.

Warranty Inclusions

1. Full-Service Coverage (First Year):
   For 12 months from purchase, we will repair or replace defective components at no cost, as determined by our technical team.
2. Parts Protection (Years 1–3):
   Non-consumable replacement parts* will be provided free of charge if proven defective under normal use during the 3-year period.
   *Non-consumable parts: Components not designed for regular replacement (e.g., motors, structural elements).

Exclusions

This Warranty does not cover:

• Consumables: Light bulbs, filters, or similar wear-and-tear items.

• Improper use: Damage from incorrect installation, modifications to wiring, or failure to follow manuals.

• External factors:

  • Shipping damage unreported within 7 business days of delivery.


  • Accidents, natural disasters, fires, or third-party service errors.


  • Costs related to installation, uninstallation, or return shipping.

Void Conditions
Your warranty becomes invalid if:
⚠️ The product is installed improperly or modified (e.g., cutting the power cord for direct wiring).
⚠️ Damage results from negligence, commercial use, or unauthorized repairs.



Shipping-Return Policy

Shipping Times: 5-10 business days



Available Shipping Methods:

• Curbside - FREE
• Threshold - $100 (delivery to front door/porch)



Return Authorization

• All returns require pre-approval via a Return Authorization (RA) number.

• Unauthorized returns (missing RA# on packaging) will be refused.



Return Eligibility

• 30-Day Window: Returns accepted within 30 days of delivery date.

• Item must be unused, uninstalled, and in its original packaging (including accessories, manuals, warranty cards, shock-absorbent materials, and freight materials)



Non-refundable Expenses

• 20% restocking fee
• Original and return shipping costs
• Taxes, duties, and brokerage fees



Reporting Shipping Damage:

• Visible Box Damage
  • Take photos of the damaged box
  • Refuse the package
  • Note the damage on the Bill of Lading or Freight Bill
• No box damage?
  • If the product is damaged, take photos and email them to us immediately.



Please email us at support@ovenelitehq.com with your order number, description of the damage, and the photos



Damage must be reported within 7 business days of delivery. Claims made after this period will not be accepted.
